High Resolution P6 Outdoor Full Color LED Display SMD3535 768x768mm Cabinet

Product Categories
Shenzhen Niyakr Technology Co., Limited
Contact Now

High Resolution P6 Outdoor Full Color LED Display SMD3535 768x768mm Cabinet

  • 1
  • 2

Brand Name : NIYAKR

Model Number : P6

Certification : CE,ROHS,EMC,UL,ISO

Place of Origin : Shenzhen,China

MOQ : 1 Square Meter

Price : USD

Payment Terms : L/C, T/T, Western Union, MoneyGram

Supply Ability : 20000 Square Meters Per Month

Delivery Time : 12-18 Working Days

Packaging Details : Wooden Case

Product Name : 6mm

Pixel density : 27777 Dots Per Sqm

Brightness : 6500 CD

Cabinet dimension : 768x768mm

Waterproof : IP65

Feature : Low consumption, stable performance, highly durable

Contact Now

High Resolution P6 Outdoor Full Color LED Display SMD3535 768x768mm Cabinet


Description:

  1. Classical structure,solid and stable.
  2. Integrating LED and IC in 1 PCB,further improve stability and ability of heat radiation.
  3. Inner circuit,effectively reducing the influence of natural factors to line connection.
  4. Supporting MBI5035 IC and PFC power supply,energy saving up to 50% and more.


Features:

1.Clear picture without flicker and distortion
2. Multiform file formats, such as VGA, Video, AVI, MOV, MPG, DAT, VOB and so on are comprehensive
3. Low consumption, stable performance, highly durable
4. High brightness & broad viewing angle, brightness can be adjusted automatically or manually
5. 3 years warranty, easy to install & maintenance
6. CE, RoHS, FCC


Specification:

Pixel pitch(mm)6.0
ConfigurationSMD3535
Module dimension(mm)192x192
Module weight(kg)0.37
Panel dimension(mm)768x768x120
Panel weight(kg)55
Pixel density(dots/㎡)27777
Flatness error(mm)≤0.1
Viewing angle120°/120°(Horizontal/Vertical)
Brightness(cd/㎡)6500
Color temperature(K)5000~9500 (Adjustable)
Contrast4000:1
Repetition frequency50/60Hz
Refresh frequency(Hz)1200
Gray scale65536
Ave. power(W/㎡)440
Max power(W/㎡)1100
Working temp./humidity-10~40℃/10%~80%RH
Storing temp./humidity-20~60℃/10%~85%RH
Panel structureIron
MaintenanceRear
ProtectionIP65/IP54
Driving modeConstant current driver
Scanning1/4
Power requirementsAC90~264V, 47~63Hz
Life time(hrs)100,000
CertificateCCC/TUV-CE/ETL, etc.


High Resolution P6 Outdoor Full Color LED Display SMD3535 768x768mm Cabinet

High Resolution P6 Outdoor Full Color LED Display SMD3535 768x768mm Cabinet
